Two PCIe Gen3 x16 slots that not only support ordinary graphics cards, but are also fully compatible with professional NVIDIA® Quadro and AMD FirePro workstation graphics solutions.
* This motherboard has passed SPECviewperf 12 tests using NVIDIA® Quadro® & NVS™ graphics cards.
Offers the best flexibility with support for Intel Xeon E3-1200 v5 and 6th generation Intel Core i3, Pentium and Celeron processors.
ECC memory modules are supported with Intel E3/Core i3/Pentium/ Celeron CPU only.
Low-power gigabit network controller that can be used for server and workstation system configurations.
Besides the ordinary Windows 10/8.1/7, this motherboard is also fully compatible with Server operating systems.
An additional external base clock generator which provides a wider range of frequencies and more precise clock waveforms.
Hyper BCLK Engine for overclocking CPUs anyway you want. Unleash the true powers of your Intel processors.
Offers the best flexibility with support for Intel Xeon E3-1200 v5 and 6th generation Intel Core i3, Pentium and Celeron processors.
ECC memory modules are supported with Intel E3/Core i3/Pentium/ Celeron CPU only.
Each parts of the hardware are modified for extreme gaming.
7.1 CH HD audio with Realtek ALC1150 audio codec, Nichicon caps and other technologies to deliver the crispest sound effects.
Choose your own preferred mouse polling rate from 125 Hz to 1000 Hz.
Enhance your mouse and keyboard with customizable macros, sniper modes, key repeat rates and repeat delay.
Use Sniper Key to shift the mouse speed when you're in sniper mode, it will greatly sharpen your accuracy.
Create your own set of keyboard hotkeys and macros with Macro Key to save the trouble.
E3V5 WS |
Fatal1ty E3V5 |
|
| Chipset | Intel - C232 | Intel - C232 |
| Form Factor | ATX | ATX |
| CPU | Supports Intel® Xeon® E3-1200 v5 Processor and 6th Generation Intel® Core™ i3/Pentium®/Celeron® Processors | |
| Socket | LGA1151 | LGA1151 |
| Memory | 4*DDR4 2133 | 4*DDR4 2133 |
| Max. Memory Support | 64GB | 64GB |
| Power Phase | 5 | 10 |
| Digi Power | No | Yes |
| PCI-E x16 | 2 | 2 |
| PCI-E x1 | 3 | 3 |
| SLI / Crossfire | Quad CrossFireX | Quad CrossFireX |
| RAID | 0, 1, 5, 10 | 0, 1, 5, 10 |
| SATA3 | 6 | 6 |
| USB 3.0 | 6 | 6 |
| USB 2.0 | 6 | 6 |
| Audio | 8CH, ALC 892, ELNA Audio Caps | 8CH, ALC 1150, Purity Sound™ 3, DTS Connect, S/PDIF |
| LAN | Intel I219LM Gigabit LAN | Intel I219V Gigabit LAN |
| COM Port | 0 | 1 Header |
| TPM | 1 Header | 1 Header |
| PS/2 | 2 | 1 |
| OS | Windows® 10 64-bit / 8.1 64-bit / 7 32-bit / 7 64-bit / Server 2012 R2 64-bit / Server 2012 64-bit / Server 2008 R2 64-bit | Windows® 10 64-bit / 8.1 64-bit / 7 32-bit / 7 64-bit |
