Jupiter A320

AM4 Socket APUs, up to 65Watts
AMD A320 Chipset
178 x 178 x 34mm / 1.07L
2 x USB 3.2 Gen1 Type-C
4 x USB 3.2 Gen1
2 x USB 2.0
DisplayPort, HDMI, D-Sub
M.2 (2280) slot for SSD (PCIe / SATA 6Gb)
M.2 (2230) slot for Wi-Fi
2W Speaker, TPM V2.0
Support DASH Standard (optional)

This model may not be sold worldwide. Please contact your local dealer for the availability of this model in your region.

Overview
Specification
Support

Where to Buy

Jupiter (A320)

CPU
- Supports AMD AM4 Socket 65W/35W APUs
Chipset
- AMD A320
Cooler
- Integrated Cooling Solution
Memory
- Supports 2 x SO-DIMM DDR4, Max. 64GB (non-ECC)
- Ryzen APU -DDR4-2933MHz
- A-series APU -DDR4-2400MHz
Graphics
- Integrated AMD Radeon. Vega Series Graphics in Ryzen Series APU
- Integrated AMD Radeon. R-Series Graphics in A-series APU
Graphics Output
- 1 x HDMI (4K@60Hz),1 x DisplayPort (4K@60Hz), 1 x D-Sub*

*Supports up to 3 displays simultaneously.
Audio
- 1 x Head Phone with Mic Jack
- 1 x Mic-In
- 1 x Speaker Out
- 1 x 2W SpeakerRealtek ALC233
Front USB
- 2 x USB 3.1 Gen1 Type-C, 2 x USB 3.1 Gen1 Type-A
Rear USB
- 2 x USB 3.1 Gen1 Type-A, 2 x USB 2.0
Storage
- M.2_1: Type 2280 PCIe Gen3 x4 & SATA 6Gb
- 1 x SATA 6Gb 2.5-inch 7mm/9.5mm Hard Drive
LAN
- 1 x RJ45 Gigabit LAN
- Realtek RTL8111GN
WLAN
- M.2 Type 2230 Key-E
Connectors
- 1 x 4-Pin Fan Connector
- 1 x DC-In Jack (Supports 19V Power Adapters)
- 1 x Internal Speaker Header
- 1 x 2-Pin Chassis Intrusion Header
Power Unit
- 90W/19V Adapter
Dimension
- Motherboard: 170 x 170 (Proprietary)
- Barebones: 178 x 178 x 34 mm (1.0L)
Security
- Kensington lock
- Key Lock
OS
- Microsoft^® Windows^® 10 64-bit / 11 64-bit
Certification
- CE, FCC
Remark
- VESA: 75 x 75mm / 100 x 100 mm
- Optional TPM 2.0 IC

Description	Language	Download
Quick Installation Guide	Multi-Language	Global	China

The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing Administrator, Inc. in the United States and other countries.

The specification is subject to change without notice in advance. The brand and product names are trademarks of their respective companies. Any configuration other than original product specification is not guaranteed.

The above user interface picture is a sample for reference. The actual user interface may vary with the updated software version.
