• CPU
  - Socket 478, Intel^® Pentium^® 4 / Celeron
  - FSB 533/400MHz
• Chipset
  - VIA^® P4M266A, supports Hyper-Threading Technology
• Memory
  - 2 x DDR, DDR266/200 non-ECC, un-buffered memory
  - Max. capacity of system memory: 2GB
• BIOS
  - 2Mb AMI BIOS with ACPI, SM BIOS 2.3.1, PnP
• Graphics
  - Integrated ProSavage8 3D Graphic
  - Memory Default 32MB
• Audio
  - AC97 CODEC
  - Channel 2 CH Audio
• LAN
  - 802.3u, 10/100 Ethernet LAN, WOL supported
  - Supports PXE
• Slots
  - AGP 4X universal
  - PCI 2 slots, PCI 2.2
  - AMR 1
• Connector
  - IDE 2 x ATA 133/100/66/33
  - Floppy 1 connector
  - SIR/CIR 1/0
  - CPU/Chassis FAN connectors
  - 20 pin ATX power connector
  - CD/AUX/ audio in
  - Front panel audio connector
• Rear Panel I/O
  ASROCK I/O
  - Keyboard PS2 x1
  - Mouse PS2 x1
  - USB2.0 4 ports default on rear panel +2 ports upgrade VIA^® header
  - Serial 1 COM Port Bracket
  - Parallel 1
  - Game/MIDI 1
  - LAN 1 x RJ45
  - Audio I/O 1
  - VGA 1
• Unique Feature
  - CPU Frequency Stepless control
  - Boot Failure Guard (B.F.G)
• Support CD
  - Drivers
  - Bundle CD includes: Anti Virus Software, ASRock PC DIY Live Demo, Audio Player, etc..
• Accessories
  - Quick Installation Guide
  - Support CD
  - Floppy/ATA 133/100 Cables
  - 1x COM Port Bracket
• Form Factor
  - Micro ATX 9.6"x7.5"
• OS
  - Microsoft^® Windows^® 98SE/ME/2000/XP compliant
