• CPU
  - Socket A (462) for AMD Athlon XP / Athlon / Duron / Sempron processor
  - FSB 333/266 MHz
• Chipset
  - Northbridge: VIA^® KT400A
  - Southbridge: VIA^® 8237
• Memory
  - Supports DDR400*/333/266 non-ECC, un-buffered memory
  - DIMM slots: 2
  - Max. capacity of system memory: 2GB



  *DDR400 for 1 DDR DIMM slot, Max. 1GB
• BIOS
  - 2Mb AMI BIOS with ACPI, SM BIOS 3.0, PnP
• Graphics
  - n/a
• Audio
  - CMedia CMI9761A 5.1 channel AC'97 audio codec
• LAN
  - VIA^® 6103 10/100 Ethernet LAN PHY
  - 802.3u, WOL supported
  - Supports PXE
• Slots
  - 1 x AGP8X/4X slot, 1.5V
  - 5 x PCI slots( PCI 2.2 compliance)
• Connector
  - 2 x SeialATA 1.5Gb/s connectors supports RAID,0,1,JBOD, SATA HDD_Hotplug
  - 2 x ATA 133/100/66 IDE connectors( supports 4 x IDE devices)
  - 1 x Floppy connector
  - CPU/Chassis FAN connectors
  - 20 pin ATX power connector
  - Power LED connector
  - CD/AUX audio in header
  - Front panel audio connector
  - 1 x USB 2.0 port pin header
  - 1 x Game port header
• Rear Panel I/O
  ASRock I/O Plus
  - 6 x USB2.0 ports
  - 1 x RJ45 LAN port
  - 1 x Serial port (COM1)
  - 1 x PS2 Keyboard connector
  - 1 x PS2 Mouse connectors
  - 1 x Parallel port (LPT1)
  - 1 x Audio ports ( Line In/Out, Mic In)
• Unique Feature
  Hybrid Booster:
  - CPU Frequency Stepless control
  - CPU Multiplier
  - CPU Vcore Adjustment
  - ASRock U-COP
  - Boot Failure Guard (B.F.G)
• Support CD
  - Drivers, Utilities, AntiVirus Software,ASRock PC DIY Demo
  - SATA driver and utility
• Accessories
  - Quick Installation Guide, Support CD, I/O shield
  - Floppy/ATA 133 Cables
  - 1 x SATA Data Cable
  - 1 x SATA 1-to-1 Power Cable
• Hardware Monitor
  - CPU Temperature Sensing
  - Motherboard Temperature Sensing
  - CPU Fan Tachometer
  - Chassis Fan Tachometer
  - Voltage Monitoring: +12V, +5V, +3.3V, Vcore
• Form Factor
  - ATX, 305mm x 178mm
• OS
  - Microsoft^® Windows^® 98SE/ME/2000/XP compliant
• Certifications
  - FCC, CE

The specification is subject to change without notice in advance. The brand and product names are trademarks of their respective companies. Any configuration other than original product specification is not guaranteed.

The above user interface picture is a sample for reference. The actual user interface may vary with the updated software version.
