• CPU
  - Support for Socket AM2+ / AM2 processors: AMD Phenom™ FX / Phenom / Athlon 64 FX / Athlon 64 X2 Dual-Core / Athlon X2 Dual-Core / Athlon 64 / Sempron processor
  - Supports CPU up to 140W
  - AMD LIVE!™ Ready
  - Supports AMD's Cool 'n' Quiet Technology
  - FSB 2600 MHz (5.2 GT/s)
  - Supports Untied Overclocking Technology
  - Supports Hyper-Transport 3.0 (HT 3.0) Technology
• Chipset
  - NVIDIA^® nForce 740a SLI
• Memory
  - Dual Channel DDR2 memory technology
  - 4 x DDR2 DIMM slots
  - Supports DDR2 1066*/800/667/533 non-ECC, un-buffered memory
  - Max. capacity of system memory: 16GB**



  *Support with AM3 / AM2+ CPU.

  **Due to the operating system limitation, the actual memory size may be less than 4GB for the reservation for system usage under Windows^® XP and Windows^® Vista™. For Windows^® XP 64-bit and Windows^® Vista™ 64-bit with 64-bit CPU, there is no such limitation.
• BIOS
  - 8Mb AMI BIOS
  - AMI Legal BIOS
  - Supports "Plug and Play"
  - ACPI 1.1 Compliance Wake Up Events
  - Supports jumperfree
  - SMBIOS 2.3.1 Support
  - CPU, DRAM, Chipset Core, HTT Voltage Multi-adjustment
  - Supports Smart BIOS
• Graphics
  - n/a
• Audio
  - 7.1 CH Windows^® Vista™ Premium Level HD Audio with Content Protection
  - DAC with 110dB dynamic range (ALC890 Audio Codec)
• LAN
  - Gigabit LAN 10/100/1000 Mb/s
  - Giga PHY RTL8211B
  - Supports Wake-On-LAN
  - Supports PXE
• Slots
  - 2 x PCI Express 2.0 x16 slots (green @ x16 mode, blue @ x8 mode)
  - 1 x PCI Express x1 slot
  - 3 x PCI slots
  - Supports NVIDIA^® SLI™
• Connector
  - 6 x SATA2 3.0 Gb/s connectors, support RAID (RAID 0, RAID 1, RAID 0+1, RAID 5, JBOD), NCQ, AHCI and Hot Plug functions
  - 1 x eSATA2 3.0 Gb/s connector (shared with 1 SATA2 port)
  - 1 x ATA133 IDE connector (supports 2 x IDE devices)
  - 1 x Floppy connector
  - 1 x IR header
  - 1 x COM port header
  - 1 x HDMI_SPDIF header
  - 1 x IEEE 1394 header
  - CPU/Chassis FAN connector
  - 24 pin ATX power connector
  - 8 pin 12V power connector
  - SLI/XFire power connector
  - CD in header
  - Front panel audio connector
  - 2 x USB 2.0 headers (support 4 USB 2.0 ports)
• Rear Panel I/O
  I/O Panel
  - 1 x PS/2 Mouse Port
  - 1 x PS/2 Keyboard Port
  - 1 x Coaxial SPDIF Out Port
  - 1 x Optical SPDIF Out Port
  - 6 x Ready-to-Use USB 2.0 Ports
  - 1 x eSATA2 Port
  - 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED)
  - 1 x IEEE 1394 Port
  - HD Audio Jack: Side Speaker / Rear Speaker / Central / Bass / Line in / Front Speaker / Microphone
• Unique Feature
  - ASRock OC Tuner
  - Intelligent Energy Saver (Support with Phenom CPU)
  - Instant Boot
  - Hybrid Booster:
  - CPU Frequency Stepless Control
  - ASRock U-COP
  - Boot Failure Guard (B.F.G.)
  - ASRock AM2 Boost: ASRock Patented Technology to boost memory performance up to 12.5%
• Support CD
  - Drivers, Utilities, AntiVirus Software (Trial Version)
• Accessories
  - 1 x ASRock SLI/XFire Switch Card
  - Quick Installation Guide, Support CD, I/O Shield
  - Floppy/ATA 133 Cables
  - 2 x SATA Data Cables (optional)
  - 1 x SATA 1 to 1 Power Cable (optional)
• Hardware Monitor
  - CPU Temperature Sensing
  - Chassis Temperature Sensing
  - CPU Fan Tachometer
  - Chassis Fan Tachometer
  - CPU Quiet Fan
  - Voltage Monitoring: +12V, +5V, +3.3V, Vcore
• Form Factor
  - ATX Form Factor: 12.0-in x 8.8-in, 30.5 cm x 22.4 cm
  - All Solid Capacitor design (100% Japan made high quality conductive polymer capacitors)
• OS
  - Microsoft^® Windows^® 7 / 7 64-bit / Vista™ / Vista™ 64-bit / XP / XP Media Center / XP 64-bit compliant
• Certifications
  - FCC, CE
