• CPU
  - Socket AM2 for AMD Athlon™ 64FX / 64X2 / 64 and Sempron processors
  - AMD LIVE!™ Ready
  - Supports AMD's Cool 'n' Quiet Technology
  - FSB 1000MHz (2.0 GT/s)
  - Supports Untied Overclocking Technology
  - Supports Hyper-Transport Technology
• Chipset
  - NVIDIA^® GeForce 6100 / nForce 430 or GeForce 6150SE / nForce 430
• Memory
  - Dual Channel DDR2 memory technology
  - 4 x DDR2 DIMM slots
  - Supports DDR2 800/667/533 non-ECC, un-buffered memory
  - Max. capacity of system memory: 8GB*



  *Due to the operating system limitation, the actual memory size may be less than 4GB for the reservation for system usage under Windows^® XP and Windows^® Vista™. For Windows^® XP 64-bit and Windows^® Vista™ 64-bit with 64-bit CPU, there is no such limitation.
• BIOS
  - 4Mb AMI BIOS
  - AMI Legal BIOS
  - Supports "Plug and Play"
  - ACPI 1.1 Compliance Wake Up Events
  - Supports Jumperfree
  - SMBIOS 2.3.1 Support
• Graphics
  - Integrated NVIDIA^® GeForce6-class graphics
  - DX9.0 VGA, Pixel Shader 3.0
  - Max. shared memory 256MB
  - Two graphics output options: Support D-Sub and DVI-D ports with DVI Graphics-SI Card by independent display controllers
• Audio
  - 7.1 CH Windows^® Vista™ Premium Level HD Audio (ALC888 Audio Codec)
• LAN
  - Gigabit LAN 10/100/1000 Mb/s
  - Giga PHY Realtek RTL8211B
  - Supports Wake-On-LAN
  - Supports PXE
• Slots
  - 2 x PCI slots
  - 1 x PCI Express x16 slot
  - 1 x PCI Express x1 slot
  - 1 x HDMR slot
• Connector
  - 4 x SATA2 3.0 Gb/s connectors, support RAID (RAID 0, RAID 1, RAID 0+1, RAID 5, JBOD), NCQ, and Hot Plug functions
  - 1 x ATA133 IDE connector (supports 2 x IDE devices)
  - 1 x Floppy connector
  - 1 x IR header
  - 1 x Game header
  - 1 x COM port header
  - 1 x HDMI_SPDIF header
  - CPU/Chassis FAN connector
  - 20 pin ATX power connector
  - 4 pin 12V power connector
  - CD in header
  - Front panel audio connector
  - 3 x USB 2.0 headers (support 6 USB 2.0 ports)
• Rear Panel I/O
  HD 8CH I/O
  - 1 x PS/2 Mouse Port
  - 1 x PS/2 Keyboard Port
  - 1 x VGA Port
  - 1 x Parallel Port (ECP/EPP support)
  - 4 x Ready-to-Use USB 2.0 Ports
  - 1 x RJ-45 Port
  - HD Audio Jack: Side Speaker / Rear Speaker / Central / Bass / Line in / Front Speaker / Microphone
• Unique Feature
  Hybrid Booster:
  - CPU Frequency Stepless Control
  - ASRock U-COP
  - Boot Failure Guard (B.F.G.)
  - ASRock AM2 Boost: ASRock Patented Technology to boost memory performance up to 12.5%
• Support CD
  - Drivers, Utilities, AntiVirus Software (Trial Version)
• Accessories
  - Quick Installation Guide, Support CD, I/O Shield
  - Floppy/ATA 133 Cables
  - 1 x SATA Data Cable (optional)
  - 1 x SATA 1 to 1 Power Cable (optional)
  - 1 x COM Port Bracket
  - 1 x HDMR card (optional)
  - 1 x HDMI_SPDIF Cable (optional)
  - 1 x DVI Graphics-SI Card
• Hardware Monitor
  - CPU Internal Temperature Sensing
  - CPU Ambient Temperature Sensing
  - Chassis Temperature Sensing
  - CPU Fan Tachometer
  - Chassis Fan Tachometer
  - CPU Quiet Fan
  - Voltage Monitoring: +12V, +5V, +3.3V, Vcore
• Form Factor
  - Micro ATX Form Factor: 9.6-in x 9.6-in, 24.4 cm x 24.4 cm
• OS
  - Microsoft^® Windows^® 2000 / XP / XP Media Center / XP 64-bit / Vista™ / Vista™ 64-bit compliant
• Certifications
  - FCC, CE
