• CPU
  - LGA 775 for Intel^® Core™ 2 Extreme / Core™ 2 Quad / Core™ 2 Duo / Pentium^® Dual Core / Celeron^® Dual Core / Celeron, supporting Penryn Quad Core Yorkfield and Dual Core Wolfdale processors
  - Compatible with FSB 2000*/1600/1333/1066/800 MHz
  - Supports Hyper-Threading Technology
  - Supports Untied Overclocking Technology
  - Supports EM64T CPU



  *In overclocking mode.
• Chipset
  - Northbridge: Intel^® P45
  - Southbridge: Intel^® ICH10R
• Memory
  - Dual Channel DDR2 memory technology
  - 4 x DDR2 DIMM slots
  - Supports DDR2 1200/1066/800/667 non-ECC, un-buffered memory
  - Max. capacity of system memory: 16GB*



  *Due to the operating system limitation, the actual memory size may be less than 4GB for the reservation for system usage under Windows^® XP and Windows^® Vista™. For Windows^® XP 64-bit and Windows^® Vista™ 64-bit with 64-bit CPU, there is no such limitation.
• BIOS
  - 8Mb AMI BIOS
  - AMI Legal BIOS
  - Supports "Plug and Play"
  - ACPI 1.1 Compliance Wake Up Events
  - Supports Jumperfree Overclocking
  - SMBIOS 2.3.1 Support
  - CPU, DRAM, NB, SB, VTT Voltage Multi-adjustment
  - Supports I. O. T. (Intelligent Overclocking Technology)
  - Supports Smart BIOS
• Graphics
  - n/a
• Audio
  - 7.1 CH Windows^® Vista™ Premium Level HD Audio with Content Protection
  - DAC with 110dB dynamic range (ALC890 Audio Codec)
• LAN
  - PCIE x1 Gigabit LAN 10/100/1000 Mb/s
  - Realtek RTL8111B/RTL8111C
  - Supports Wake-On-LAN
  - Supports Dual GLAN with Teaming function
  - Supports PXE
• Slots
  - Supports ATI™ CrossFire™
  - 2 x PCI Express 2.0 x16 slots (green @ x16 mode, blue @ x8 mode)
  - 3 x PCI Express x1 slots
  - 2 x PCI slots
• Connector
  - 6 x SATA2 3.0 Gb/s connectors, support RAID (RAID 0, RAID 1, RAID 10, RAID 5 and Intel^® Matrix Storage), NCQ, AHCI and Hot Plug functions
  - 2 x eSATA2 3.0 Gb/s connectors (shared with 2 SATA2 ports)
  - 1 x ATA133 IDE connector (supports 2 x IDE devices)
  - 1 x Floppy connector
  - 1 x IR header
  - 1 x COM port header
  - 1 x HDMI_SPDIF header
  - 1 x IEEE 1394 header
  - CPU/Chassis FAN connector
  - 24 pin ATX power connector
  - 8 pin 12V power connector
  - CD in header
  - Front panel audio connector
  - 2 x USB 2.0 headers (support 4 USB 2.0 ports)
  - 1 x USB/WiFi header
• Rear Panel I/O
  ASRock DualLAN_SPDIF I/O
  - 1 x PS/2 Mouse Port
  - 1 x PS/2 Keyboard Port
  - 1 x Coaxial SPDIF Out Port
  - 1 x Optical SPDIF Out Port
  - 6 x Ready-to-Use USB 2.0 Ports
  - 2 x eSATA2 Ports
  - 2 x RJ-45 LAN Ports with LED (ACT/LINK LED and SPEED LED)
  - 1 x IEEE 1394 Port
  - HD Audio Jack: Side Speaker / Rear Speaker / Central / Bass / Line in / Front Speaker / Microphone
• Unique Feature
  - ASRock OC Tuner
  - Intelligent Energy Saver
  - Instant Boot
  - Hybrid Booster:
  - CPU Frequency Stepless Control
  - ASRock U-COP
  - Boot Failure Guard (B.F.G.)
• Support CD
  - Drivers, Utilities, AntiVirus Software (Trial Version)
• Accessories
  - Quick Installation Guide, Support CD, I/O Shield
  - Floppy/ATA 133 Cables
  - 4 x SATA Data Cables (optional)
  - 1 x SATA 1 to 1 Power Cable (optional)
• Hardware Monitor
  - CPU Temperature Sensing
  - Chassis Temperature Sensing
  - CPU Fan Tachometer
  - Chassis Fan Tachometer
  - CPU Quiet Fan
  - Voltage Monitoring: +12V, +5V, +3.3V, CPU Vcore
• Form Factor
  - ATX Form Factor: 12.0-in x 8.8-in, 30.5 cm x 22.4 cm
  - All Solid Capacitor design (100% Japan made high quality conductive polymer capacitors)
• OS
  - Microsoft^® Windows^® 2000 / XP / XP 64-bit / Vista™ / Vista™ 64-bit compliant
• Certifications
  - FCC, CE
