• CPU
  - LGA 775 for Intel^® Core™ 2 Extreme / Core™ 2 Quad / Core™ 2 Duo / Pentium^® Dual Core / Celeron^® Dual Core / Celeron, supporting Penryn Quad Core Yorkfield and Dual Core Wolfdale processors
  - Supports FSB 1333/1066/800/533 MHz
  - Supports Hyper-Threading Technology
  - Supports Untied Overclocking Technology
  - Supports EM64T CPU
• Chipset
  - Northbridge: Intel^® G41
  - Southbridge: Intel^® ICH7
• Memory
  - Dual Channel DDR2 memory technology
  - 2 x DDR2 DIMM slots
  - Supports DDR2 1066(OC)/800/667/533* non-ECC, un-buffered memory
  - Max. capacity of system memory: 8GB**



  *DDR2 533 is supported with FSB 533 CPU.

  **Due to the operating system limitation, the actual memory size may be less than 4GB for the reservation for system usage under Windows^® XP and Windows^® Vista™. For Windows^® XP 64-bit and Windows^® Vista™ 64-bit with 64-bit CPU, there is no such limitation.

  ***In order to maximize the system memory, please install 4GB memory module with 16 cells or 2GB memory modules with at least 8 cells.
• BIOS
  - 8Mb AMI BIOS
  - AMI Legal BIOS
  - Supports "Plug and Play"
  - ACPI 1.1 Compliance Wake Up Events
  - SMBIOS 2.3.1 Support
  - CPU, DRAM, NB, SB, VTT Voltage Multi-adjustment
  - Supports Smart BIOS
• Graphics
  - Intel^® Graphics Media Accelerator X4500
  - Pixel Shader 4.0, DirectX 10
  - Max. shared memory 1759MB*
  - Two graphics output options: Support DVI-D and D-Sub ports by independent display controllers
  - Supports DVI with max. resolution up to 1920x1200 @ 75Hz
  - Supports D-Sub with max. resolution up to 2048x1536 @ 60Hz
  - Supports HDCP function with DVI-D port
  - Supports Full HD 1080p Blu-ray (BD) / HD-DVD playback with DVI-D port



  *The shared memory size is dynamically controlled by VGA driver, and the Max. shared memory size will be available only when more than 4GB memory is installed under 64-bit OS.
• Audio
  - 7.1 CH Windows^® Vista™ Premium Level HD Audio (VIA^® VT1708S Audio Codec)
• LAN
  - PCIE x1 Gigabit LAN 10/100/1000 Mb/s
  - Realtek RTL8111DL
  - Supports Wake-On-LAN
  - Supports PXE
• Slots
  - 1 x PCI Express x16 slot
  - 1 x PCI Express x1 slot
  - 2 x PCI slots
• Connector
  - 4 x SATA2 3.0 Gb/s connectors (No support for RAID and Hot Plug functions)
  - 1 x ATA100 IDE connector (supports 2 x IDE devices)
  - 1 x Floppy connector
  - 1 x Print port header
  - 1 x IR header
  - 1 x COM port header
  - CPU/Chassis FAN connector
  - 24 pin ATX power connector
  - 4 pin 12V power connector
  - CD in header
  - Front panel audio connector
  - 2 x USB 2.0 headers (support 4 USB 2.0 ports)
• Rear Panel I/O
  I/O Panel
  - 1 x PS/2 Mouse Port
  - 1 x PS/2 Keyboard Port
  - 1 x VGA/D-Sub Port
  - 1 x VGA/DVI-D Port
  - 4 x Ready-to-Use USB 2.0 Ports
  - 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED)
  - HD Audio Jack: Side Speaker / Rear Speaker / Central / Bass / Line in / Front Speaker / Microphone
• Unique Feature
  - ASRock OC Tuner
  - Intelligent Energy Saver
  - Instant Boot
  - Hybrid Booster:
  - CPU Frequency Stepless Control
  - ASRock U-COP
  - Boot Failure Guard (B.F.G.)
• Support CD
  - Drivers, Utilities, AntiVirus Software (Trial Version)
• Accessories
  - Quick Installation Guide, Support CD, I/O Shield
  - ATA 100 Cable
  - 1 x SATA Data Cable (optional)
  - 1 x SATA 1 to 1 Power Cable (optional)
  - 1 x DVI-to-HDMI Converter
• Hardware Monitor
  - CPU Temperature Sensing
  - Chassis Temperature Sensing
  - CPU Fan Tachometer
  - Chassis Fan Tachometer
  - CPU Quiet Fan
  - Voltage Monitoring: +12V, +5V, +3.3V, CPU Vcore
• Form Factor
  - Micro ATX Form Factor: 9.6-in x 8.6-in, 24.4 cm x 21.8 cm
• OS
  - Microsoft^® Windows^® 2000 / XP / XP 64-bit / Vista™ / Vista™ 64-bit compliant
• Certifications
  - FCC, CE

The specification is subject to change without notice in advance. The brand and product names are trademarks of their respective companies. Any configuration other than original product specification is not guaranteed.
