• CPU
  - LGA 775 for Intel^® Dual Core Core™ 2 Extreme / Core™ 2 Duo / Pentium^® Dual Core / Celeron, supporting Dual Core Wolfdale processors
  - Compatible with all FSB 1333**/1066/800/533 MHz CPUs except Quad Core
  - Supports Hyper-Threading Technology
  - Supports Untied Overclocking Technology
  - Supports EM64T CPU



  *In overclocking mode. Under this situation, PCIE frequency will also be overclocked to 115MHz.
• Chipset
  - Northbridge: Intel^® 945GC A2
  - Southbridge: Intel^® ICH7
• Memory
  - Dual Channel DDR2 memory technology
  - 2 x DDR2 DIMM slots
  - Supports DDR2 667/533 non-ECC, un-buffered memory
  - Max. capacity: 4GB*



  *Due to the chipset limitation, the actual memory size may be less than 4GB for the reservation for system usage under Windows^® XP, Windows^® XP 64-bit, Windows^® Vista™ and Windows^® Vista™ 64-bit.
• BIOS
  - 4Mb AMI BIOS
  - AMI Legal BIOS
  - Supports "Plug and Play"
  - ACPI 1.1 Compliance Wake Up Events
  - Supports Jumperfree
  - SMBIOS 2.3.1 Support
• Graphics
  - Intel^® Graphics Media Accelerator 950
  - Pixel Shader 2.0, DirectX 9.0
  - Max. shared memory 224MB
• Audio
  - 5.1 CH Windows^® Vista™ Premium Level HD Audio (ALC662 Audio Codec)
• LAN
  - Realtek PCIE x1 LAN 8101E
  - Speed: 10/100 Ethernet
  - Supports Wake-On-LAN
  - Supports PXE
• Slots
  - 1 x PCI Express x16 slot
  - 1 x PCI Express x1 slot
  - 2 x PCI slots
  - 1 x HDMR slot
• Connector
  - 4 x SATA2 3.0 Gb/s connectors (No support for RAID and Hot Plug functions)
  - 1 x ATA100 IDE connector (supports 2 x IDE devices)
  - 1 x Floppy connector
  - 1 x DeskExpress Hot Plug Detection header
  - 1 x COM port header
  - CPU/Chassis FAN connector
  - 20 pin ATX power connector
  - 4 pin 12V power connector
  - CD in header
  - Front panel audio connector
  - 2 x USB 2.0 headers (support 4 USB 2.0 ports)
• Rear Panel I/O
  ASRock 6CH Premium I/O
  - 1 x PS/2 Mouse Port
  - 1 x PS/2 Keyboard Port
  - 1 x VGA Port
  - 1 x Parallel Port (ECP/EPP support)
  - 4 x Ready-to-Use USB 2.0 Ports
  - 1 x RJ-45 LAN Port
  - HD Audio Jack: Rear Speaker / Central / Bass / Line in / Front Speaker / Microphone
• Unique Feature
  Hybrid Booster:
  - CPU Frequency Stepless Control
  - ASRock U-COP
  - Boot Failure Guard (B.F.G.)
• Support CD
  - Drivers, Utilities, AntiVirus Software (Trial Version)
• Accessories
  - Quick Installation Guide, Support CD, I/O Shield
  - Floppy/ATA 100 Cables
  - 1 x SATA Data Cable (optional)
  - 1 x SATA 1 to 1 Power Cable (optional)
  - 1 x COM Port Bracket
• Hardware Monitor
  - CPU Temperature Sensing
  - Chassis Temperature Sensing
  - CPU Fan Tachometer
  - Chassis Fan Tachometer
  - CPU Quiet Fan
  - Voltage Monitoring: +12V, +5V, +3.3V, CPU Vcore
• Form Factor
  - Micro ATX Form Factor: 9.6-in x 9.0-in, 24.4 cm x 22.9 cm
• OS
  - Microsoft^® Windows^® 2000 / XP / XP 64-bit / Vista™ / Vista™ 64-bit compliant
• Certifications
  - FCC, CE

The specification is subject to change without notice in advance. The brand and product names are trademarks of their respective companies. Any configuration other than original product specification is not guaranteed.

The above user interface picture is a sample for reference. The actual user interface may vary with the updated software version.
