• CPU
  - Intel^® Atom™ Processor D425 (1.8 GHz)
  - Supports Hyper-Threading Technology
  - Supports Untied Overclocking Technology
  - Supports EM64T CPU
• Chipset
  - Southbridge: Intel^® NM10 Express
• Memory
  - 2 x DDR3 DIMM slots
  - Supports DDR3 800 non-ECC, un-buffered memory
  - Max. capacity of system memory: 8GB*



  *Due to the operating system limitation, the actual memory size may be less than 4GB for the reservation for system usage under Windows^® 32-bit OS. For Windows^® 64-bit OS with 64-bit CPU, there is no such limitation.
• BIOS
  - 4Mb AMI BIOS
  - AMI Legal BIOS
  - Supports "Plug and Play"
  - ACPI 1.1 Compliance Wake Up Events
  - Supports jumperfree
  - SMBIOS 2.3.1 Support
  - VCCM, SB Voltage Multi-adjustment
• Graphics
  - Intel^® Graphics Media Accelerator 3150
  - Pixel Shader 2.0, DirectX 9.0
  - Max. shared memory 384MB
  - Supports D-Sub with max. resolution up to 2048x1536 @ 60Hz
• Audio
  - 5.1 CH HD Audio (Realtek ALC662 Audio Codec)
• LAN
  - PCIE x1 Gigabit LAN 10/100/1000 Mb/s
  - Atheros^® AR8151
  - Supports Wake-On-LAN
  - Supports PXE
• Slots
  - 1 x PCI slot
• Connector
  - 2 x SATA2 3.0 Gb/s connectors, support NCQ, AHCI and Hot Plug functions
  - CPU/Chassis FAN connector
  - 24 pin ATX power connector
  - Front panel audio connector
  - 2 x USB 2.0 headers (support 4 USB 2.0 ports)
• Rear Panel I/O
  I/O Panel
  - 1 x PS/2 Mouse Port
  - 1 x PS/2 Keyboard Port
  - 1 x Parallel Port (ECP/EPP Support)
  - 1 x Serial Port: COM1
  - 1 x VGA Port
  - 4 x Ready-to-Use USB 2.0 Ports
  - 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED)
  - HD Audio Jack: Line in / Front Speaker / Microphone
• Unique Feature
  - ASRock OC Tuner
  - Instant Boot
  - ASRock Instant Flash
  - ASRock OC DNA
  - ASRock APP Charger
  - Hybrid Booster:
  - CPU Frequency Stepless Control
  - ASRock U-COP
  - Boot Failure Guard (B.F.G.)
• Support CD
  - Drivers, Utilities, AntiVirus Software (Trial Version), ASRock Software Suite (CyberLink DVD Suite - OEM and Trial; Creative Sound Blaster X-Fi MB - Trial)
• Accessories
  - Quick Installation Guide, Support CD, I/O Shield
  - 2 x SATA Data Cables (optional)
• Hardware Monitor
  - CPU Temperature Sensing
  - Chassis Temperature Sensing
  - CPU Fan Tachometer
  - Chassis Fan Tachometer
  - CPU Quiet Fan
  - Voltage Monitoring: +12V, +5V, +3.3V, CPU Vcore
• Form Factor
  - Mini-ITX Form Factor: 6.7-in x 6.7-in, 17.0 cm x 17.0 cm
  - Solid Capacitor for CPU Power
• OS
  - Microsoft^® Windows^® 7 / 7 64-bit / Vista™ / Vista™ 64-bit / XP / XP 64-bit compliant
• Certifications
  - FCC, CE
  - ErP/EuP Ready (ErP/EuP ready power supply is required)

The specification is subject to change without notice in advance. The brand and product names are trademarks of their respective companies. Any configuration other than original product specification is not guaranteed.

The above user interface picture is a sample for reference. The actual user interface may vary with the updated software version.
