Server / Workstation Series

	Z77 WS Premium Gold Caps Digi Power Design, 8 + 4 Power Phase Design Supports Dual Channel DDR3 3000+(OC) 5 x PCIe 3.0 x16 Slots, 1 x PCIe 2.0 x16 Slot, Supports AMD 4-Way CrossFireX™ and NVIDIA 4-Way SLI™ Supports Intel HD Graphics with Built-in Visuals 12 USB 3.0 (4 Front, 8 Rear), 6 SATA3 7.1 CH HD Audio with Content Protection (Realtek ALC898 Audio Codec) Supports ASRock XFast 555, Interactive UEFI, Intel Smart Connect, Intel Rapid Start Free Bundle : CyberLink MediaEspresso 6.5 Trial, ASRock MAGIX Multimedia Suite
	C216 WS Premium Gold Caps Digi Power Design, 8 + 4 Power Phase Design Supports Dual Channel DDR3 1600 2 x PCIe 3.0 x16 Slots, 1 x PCIe 2.0 x16 Slot, Supports AMD 3-Way CrossFireX Supports Broadcom Dual PCIE GLAN 8 USB 3.0 (2 Front, 6 Rear), 6 SATA3, 1 eSATA3 7.1 CH HD Audio with Content Protection (Realtek ALC892 Audio Codec)
	H77WS-DL 100% All Solid Capacitor design Supports Dual Channel DDR3 1600 1 x PCIe 3.0 x16 Slot, 1 x PCIe 2.0 x16 Slot, Support AMD Quad CrossFireX™ and CrossFireX™ PCIE Dual Gigabit LAN with Teaming Function Supports Intel HD Graphics with Built-in Visuals Combo Cooler Option (C.C.O.) Supports ASRock XFast RAM, XFast LAN, XFast USB, Crashless BIOS Supports Intel Smart Connect Technology, Intel Rapid Start Technology
	EP2C602-4L/D16 Dual Socket R (LGA2011), supports Intel Xeon 5-1600/2600/4600 & v2 series Supports Quad Channel DDR3 1600 memory, 16 DIMM slots, Max. 256GB 4 PCIe 3.0 x16 slots (PCIE3/PCIE6 : x16 mode, PCIE4/PCIE5: x8 mode) 1 PCIe 3.0 x4, 1 PCI ASPEED AST2300 graphics 1 VGA : D-Sub 8 SATA2 (3.0 Gb/s) by Intel C602, Supports RAID 0, 1, 5, 10 2 SATA3 (6.0 Gb/s) by Intel C602, Supports RAID 0, 1 7 USB 2.0 (2 from rear I/O, 4 from onboard headers, 1 Type A port) Integrated IPMI 2.0 with KVM and Dedicated LAN (RTL8211E) 4 Intel 82574L LAN, Support PCIE Quad Gigabit LAN with Teaming function
	EP2C602/D16 Dual Socket R (LGA2011), supports IntelXeon 5-1600/2600/4600 & v2 series Supports Quad Channel DDR3 1600 memory, 16 DIMM slots, Max. 256GB 4 PCIe 3.0 x16 slots (PCIE3/PCIE6 : x16 mode, PCIE4/PCIE5: x8 mode) 1 PCIe 3.0 x4, 1 PCI ASPEED AST2300 graphics 1 VGA : D-Sub 8 SATA2 (3.0 Gb/s) by Intel C602, Supports RAID 0, 1, 5, 10 2 SATA3 (6.0 Gb/s) by Intel C602, Supports RAID 0, 1 7 USB 2.0 (2 from rear I/O, 4 from onboard headers, 1 Type A port) Integrated IPMI 2.0 with KVM and Dedicated LAN (RTL8211E) 2 Intel 82574L LAN, Support PCIE Dual Gigabit LAN with Teaming function
	EP2C602-4L Dual Socket R (LGA2011), supports Intel Xeon 5-1600/2600/4600 & v2 series Supports Quad Channel DDR3 1600 memory, 8 DIMM slots, Max. 128GB 5 PCIe 3.0 x16 slots (PCIE3/PCIE6/PCIE7 : x16 mode, PCIE4/PCIE5: x8 mode) 1 PCIe 3.0 x4, 1 PCI ASPEED AST2300 graphics 1 VGA : D-Sub 2 SATA3 (6.0 Gb/s), 8 SATA2 (3.0 Gb/s) by Intel C602, Supports RAID 0, 1, 5, 10 4 SATA3 (6.0 Gb/s) by Marvell SE9230, Supports RAID 0, 1, 10 7 USB 2.0 (2 from rear I/O, 4 from onboard headers, 1 Type A port) Integrated IPMI 2.0 with KVM and Dedicated LAN (RTL8211E) 4 Intel 82574L LAN, Support PCIE Quad Gigabit LAN with Teaming function
	EP2C602 Dual Socket R (LGA2011), supports Intel Xeon 5-1600/2600/4600 & v2 series Supports Quad Channel DDR3 1600 memory, 8 DIMM slots, Max. 128GB 5 PCIe 3.0 x16 slots (PCIE3/PCIE6/PCIE7 : x16 mode, PCIE4/PCIE5: x8 mode) 1 PCIe 3.0 x4, 1 PCI ASPEED AST2300 graphics 1 VGA : D-Sub 2 SATA3 (6.0 Gb/s), 8 SATA2 (3.0 Gb/s) by Intel C602, Supports RAID 0, 1, 5, 10 4 SATA3 (6.0 Gb/s) by Marvell SE9230, Supports RAID 0, 1, 10 7 USB 2.0 (2 from rear I/O, 4 from onboard headers, 1 Type A port) Integrated IPMI 2.0 with KVM and Dedicated LAN (RTL8211E) 2 Intel 82574L LAN, Support PCIE Dual Gigabit LAN with Teaming function
	EN2C602-4L/D12 Dual Socket B2 (LGA1356) supports Intel Xeon E5-2400/1400 Series Processors Supports Triple Channel DDR3 1600 memory, 12 DIMM slots, Max. 192GB 3 PCIe 3.0 x16 slots (PCIE3/ PCIE6 : x16 mode, PCIE5: x8 mode) 1 PCIe 3.0 x4, 1 PCIe 2.0 x1, 2 PCI ASPEED AST2300 graphics 1 VGA : D-Sub 8 SATA2 (3.0 Gb/s) by Intel C602, Supports RAID 0, 1, 5, 10 2 SATA3 (6.0 Gb/s) by Intel C602, Supports RAID 0, 1 4 SATA3 (6.0 Gb/s), Supports RAID 0, 1, 10 by Marvell SE9230 7 USB 2.0 (2 from rear I/O, 4 from onboard headers, 1 Type A port) Integrated IPMI 2.0 with KVM and Dedicated LAN (RTL8211E) 4 Intel 82574L LAN, Support PCIE Quad Gigabit LAN with Teaming function
	EN2C602/D12 Dual Socket B2 (LGA1356) supports Intel Xeon E5-2400/1400 Series Processors Supports Triple Channel DDR3 1600 memory, 12 DIMM slots, Max. 192GB 3 PCIe 3.0 x16 slots (PCIE3/ PCIE6 : x16 mode, PCIE5: x8 mode) 1 PCIe 3.0 x4, 1 PCIe 2.0 x1, 2 PCI ASPEED AST2300 graphics 1 VGA : D-Sub 8 SATA2 (3.0 Gb/s) by Intel C602, Supports RAID 0, 1, 5, 10 2 SATA3 (6.0 Gb/s) by Intel C602, Supports RAID 0, 1 4 SATA3 (6.0 Gb/s), Supports RAID 0, 1, 10 by Marvell SE9230 7 USB 2.0 (2 from rear I/O, 4 from onboard headers, 1 Type A port) Integrated IPMI 2.0 with KVM and Dedicated LAN (RTL8211E) 2 Intel 82574L LAN, Support PCIE Dual Gigabit LAN with Teaming function
	EN2C602-4L 100% All Solid Capacitor design Dual Socket B2 (LGA1356) supports Intel Xeon E5-2400/1400 Series Processors Supports Triple Channel DDR3 1600 memory, 8 DIMM slots, Max. 128GB 3 PCIe 3.0 x16 slots (1 PCIE6: x16 mode ; 2 PCIE6/PCIE4: x16/x0 mode or x8/x8 mode) 1 PCIe 3.0 x4, 1 PCIe 2.0 x1, 1 PCI ASPEED AST2300 graphics 1 VGA : D-Sub 7 USB 2.0 (2 from rear I/O, 4 from onboard headers, 1 Type A port) 2 SATA3 6.0 Gb/s and 8 SATA2 3.0 Gb/s connectors by Intel C602, support RAID (RAID 0, RAID 1, RAID 5, RAID 10 and Intel Rapid Storage) 2 SATA3 6.0 Gb/s connectors by Marvell SE9220, support RAID (RAID 0 and RAID 1) 1 Realtek RTL8211E for dedicated IPMI management GLAN 4 Intel 82574L LAN, Support PCIE Quad Gigabit LAN (with Teaming function)
	EN2C602 100% All Solid Capacitor design Dual Socket B2 (LGA1356) supports Intel Xeon E5-2400/1400 Series Processors Supports Triple Channel DDR3 1600 memory, 8 DIMM slots, Max. 128GB 3 PCIe 3.0 x16 slots (1 PCIE6: x16 mode ; 2 PCIE6/PCIE4: x16/x0 mode or x8/x8 mode) 1 PCIe 3.0 x4, 1 PCIe 2.0 x1, 1 PCI ASPEED AST2300 graphics 1 VGA : D-Sub 7 USB 2.0 (2 from rear I/O, 4 from onboard headers, 1 Type A port) 2 SATA3 6.0 Gb/s and 8 SATA2 3.0 Gb/s connectors by Intel C602, support RAID (RAID 0, RAID 1, RAID 5, RAID 10 and Intel Rapid Storage) 2 SATA3 6.0 Gb/s connectors by Marvell SE9220, support RAID (RAID 0 and RAID 1) 1 Realtek RTL8211E for dedicated IPMI management GLAN 2 Intel 82574L LAN, Support PCIE Dual Gigabit LAN (with Teaming function)
	E3C204-4L 100% All Solid Capacitor design Single Socket H2(LGA1155), supports Intel Xeon E3-1200 & v2 Series and 2nd / 3rd Generation Core™ i3, Pentium, Celeron Processors Supports Dual Channel DDR3 1600 memory, 4 DIMM slots, Max. 32GB 2 PCIe 3.0 x16 slots (PCIE6/PCIE4: x16/x0 mode or x8/x8 mode) 1 PCIe 2.0 x4, 2 PCIe 2.0 x1, 1 PCI ASPEED AST2300 graphics 1 VGA：D-Sub 7 USB 2.0 (2 from rear I/O, 4 from onboard headers, 1 Type A port) 2 SATA3 6.0 Gb/s and 4 SATA2 3.0 Gb/s connectors by Intel C204, support RAID (RAID 0, RAID 1, RAID 10 and Intel Rapid Storage) 2 SATA3 6.0 Gb/s connectors by Marvell SE9172, support RAID (RAID 0 and RAID 1) 1 Realtek RTL8211E for dedicated IPMI management GLAN 4 Intel 82574L LAN, Support PCIE Quad Gigabit LAN (with Teaming function)
	E3C204 100% All Solid Capacitor design Single Socket H2(LGA1155), supports Intel Xeon E3-1200 & v2 Series and 2nd / 3rd Generation Core™ i3, Pentium, Celeron Processors Supports Dual Channel DDR3 1600 memory, 4 DIMM slots, Max. 32GB 2 PCIe 3.0 x16 slots (PCIE6/PCIE4: x16/x0 mode or x8/x8 mode) 1 PCIe 2.0 x4, 2 PCIe 2.0 x1, 1 PCI ASPEED AST2300 graphics 1 VGA：D-Sub 7 USB 2.0 (2 from rear I/O, 4 from onboard headers, 1 Type A port) 2 SATA3 6.0 Gb/s and 4 SATA2 3.0 Gb/s connectors by Intel C204, support RAID (RAID 0, RAID 1, RAID 10 and Intel Rapid Storage) 2 SATA3 6.0 Gb/s connectors by Marvell SE9172, support RAID (RAID 0 and RAID 1) 1 Realtek RTL8211E for dedicated IPMI management GLAN 2 Intel 82574L LAN, Support PCIE Dual Gigabit LAN (with Teaming function)
	E3C204-V4L 100% All Solid Capacitor design Single Socket H2(LGA1155), supports Intel Xeon E3-1200 & v2 Series and 2nd / 3rd Generation Core™ i3, Pentium, Celeron Processors Supports Dual Channel DDR3 1600 memory, 4 DIMM slots, Max. 32GB 2 PCIe 3.0 x16 slots (PCIE6/PCIE4: x16/x0 mode or x8/x8 mode) 1 PCIe 2.0 x4, 2 PCIe 2.0 x1, 1 PCI ASPEED AST1300 graphics 1 VGA：D-Sub 7 USB 2.0 (2 from rear I/O, 4 from onboard headers, 1 Type A port) 2 SATA3 6.0 Gb/s and 4 SATA2 3.0 Gb/s connectors by Intel C204, support RAID (RAID 0, RAID 1, RAID 10 and Intel Rapid Storage) 2 SATA3 6.0 Gb/s connectors by Marvell SE9172, support RAID (RAID 0 and RAID 1) 4 Intel 82574L LAN, Support PCIE Quad Gigabit LAN (with Teaming function)
	E3C204-V+ 100% All Solid Capacitor design Single Socket H2(LGA1155), supports Intel Xeon E3-1200 & v2 Series and 2nd / 3rd Generation Core™ i3, Pentium, Celeron Processors Supports Dual Channel DDR3 1600 memory, 4 DIMM slots, Max. 32GB 2 PCIe 3.0 x16 slots (PCIE6/PCIE4: x16/x0 mode or x8/x8 mode) 1 PCIe 2.0 x4, 2 PCIe 2.0 x1, 1 PCI ASPEED AST1300 graphics 1 VGA：D-Sub 7 USB 2.0 (2 from rear I/O, 4 from onboard headers, 1 Type A port) 2 SATA3 6.0 Gb/s and 4 SATA2 3.0 Gb/s connectors by Intel C204, support RAID (RAID 0, RAID 1, RAID 10 and Intel Rapid Storage) 2 SATA3 6.0 Gb/s connectors by Marvell SE9172, support RAID (RAID 0 and RAID 1) 2 x Intel 82574L, Support PCIE Dual Gigabit LAN (with Teaming function)
	AD2550R/U3S3 Intel Atom D2550 Dual-Core 1.86GHz (10W) Processor Intel ICH10R Express Chipset Up to 4GB single channel SO-DIMM 5 SATA2 3.0Gbps Ports support RAID 0, 1, 5, 10 2 SATA3 6.0Gbps Ports control by Marvell SE9172 Support eSATA Dual Intel 82574L Gigabit LAN ports (with Teaming function) 4 x USB 3.0 ports (2 rear ports +2 via headers ), 11 x USB 2.0 ports (6 rear ports + 4 via headers + 1 Type A connector) 1 (x1) PCI-E (in x16) slot Integrated Intel GMA3600 Graphics
