• A-Style
  - ASRock Cloud
  - Purity Sound™
  - HDMI-In
• CPU
  - Supports Socket FM2+ 95W / FM2 100W processors
  - Digi Power design
  - 8 + 2 Power Phase design
• Chipset
  - AMD A88X (Bolton-D4)
• Memory
  - Dual Channel DDR3 Memory Technology
  - 4 x DDR3 DIMM Slots
  - Supports DDR3 2600+(OC)*/2400(OC)/2133/1866/1600/1333/1066 non-ECC, un-buffered memory
  - Max. capacity of system memory: 64GB**
  - Supports Intel^® Extreme Memory Profile (XMP) 1.3 / 1.2
  - Supports AMD Memory Profile Technology (AMP) up to AMP 2400



  *DDR3 2600+ is only supported with two DIMMs.

  **Due to the operating system limitation, the actual memory size may be less than 4GB for the reservation for system usage under Windows^® 32-bit OS. For Windows^® 64-bit OS with 64-bit CPU, there is no such limitation.
• BIOS
  - 2 x 64Mb AMI UEFI Legal BIOS with multilingual GUI support (1 x Main BIOS and 1 x Backup BIOS)
  - Supports Secure Backup UEFI Technology
  - Supports "Plug and Play"
  - ACPI 1.1 Compliant wake up events
  - Supports jumperfree
  - SMBIOS 2.3.1 support
  - DRAM, VDDP, VDDR Voltage multi-adjustment
• Graphics
  - Integrated AMD Radeon™ R7/R5 Series Graphics in A-series APU
  - DirectX 11.1, Pixel Shader 5.0 with FM2+ CPU. DirectX 11, Pixel Shader 5.0 with FM2 CPU.
  - Max. shared memory 2GB
  - Four graphics output options: D-Sub, DVI-D, HDMI and DisplayPort
  - Supports Quad Monitor with FM2+ CPU. Supports Triple Monitor with FM2 CPU.
  - Supports HDMI with max. resolution up to 4K x 2K (4096x2160) @ 24Hz
  - Supports Dual-link DVI-D with max. resolution up to 2560x1600 @ 60Hz
  - Supports D-Sub with max. resolution up to 1920x1200 @ 60Hz
  - Supports DisplayPort 1.2 with max. resolution up to 4K x 2K (4096x2400) @ 60Hz or 4K x 2K (4096x2160) @ 60Hz
  - Supports DP++
  - Supports Multi-Streaming
  - Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and HBR (High Bit Rate Audio) with HDMI Port (Compliant HDMI monitor is required)
  - Supports Blu-ray Stereoscopic 3D with HDMI Port
  - Supports AMD Steady Video™ 2.0: New video post processing capability for automatic jitter reduction on home/online video
  - Supports HDCP with DVI-D, HDMI and DisplayPort Ports
  - Supports Full HD 1080p Blu-ray (BD) playback with DVI-D, HDMI and DisplayPort ports



  *Only FM2+ APU can support up to 4096x2160 resolution display VIA^® HDMI port.
• Audio
  - 7.1 CH HD Audio with Content Protection (Realtek ALC1150 Audio Codec)
  - Premium Blu-ray Audio support
  - Supports Purity Sound™
  - 115dB SNR DAC with differential amplifier
  - TI^® NE5532 Premium Headset Amplifier (Supports up to 600 ohm headsets)
  - Direct Drive Technology
  - EMI shielding cover
  - PCB isolate shielding
  - Supports DTS Connect
• LAN
  - PCIE x1 Gigabit LAN 10/100/1000 Mb/s
  - Qualcomm^® Atheros^® AR8171
  - Supports Qualcomm^® Atheros^® Security Wake On Internet Technology
  - Supports Wake-On-LAN
  - Supports Energy Efficient Ethernet 802.3az
  - Supports PXE
• Slots
  - 2 x PCI Express 3.0 x16 Slots (PCIE2/PCIE4: single at x16 (PCIE2); dual at x8 (PCIE2) / x8 (PCIE4))
  - 1 x PCI Express 2.0 x16 Slot (PCIE5 @ x4 mode)
  - 2 x PCI Express 2.0 x1 Slots
  - 2 x PCI Slots
  - Supports AMD Quad CrossFireX™, 3-Way CrossFireX™, CrossFireX™ and Dual Graphics



  *PCIE 3.0 is only supported with FM2+ CPU. With FM2 CPU, it only supports PCIE 2.0.
  If you install Carrizo CPU, system only supports PCIE2 GEN3 x8 due to CPU limitation.
• Storage
  - 7 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0, RAID 1, RAID 5 and RAID 10), NCQ, AHCI and Hot Plug
• Connector
  - 1 x IR Header
  - 1 x COM Port Header
  - 1 x Chassis Intrusion Header
  - 1 x Power LED Header
  - 2 x CPU Fan Connectors (1 x 4-pin, 1 x 3-pin)
  - 3 x Chassis Fan Connectors (1 x 4-pin, 2 x 3-pin)
  - 1 x Power Fan Connector (3-pin)
  - 1 x 24 pin ATX Power Connector
  - 1 x 8 pin 12V Power Connector
  - 1 x XFire Power Connector
  - 1 x Front Panel Audio Connector
  - 3 x USB 2.0 Headers (Support 6 USB 2.0 ports)
  - 1 x USB 3.1 Gen1 Header by AMD A88X (Bolton-D4) (Supports 2 USB 3.1 Gen1 ports)
  - 1 x Dr. Debug with LED
  - 1 x Power Switch with LED
  - 1 x Reset Switch with LED
  - 1 x BIOS Selection Switch
• Rear Panel I/O
  - 1 x PS/2 Mouse/Keyboard Port
  - 1 x D-Sub Port
  - 1 x DVI-D Port
  - 1 x HDMI-Out Port
  - 1 x HDMI-In Port
  - 1 x DisplayPort
  - 1 x Optical SPDIF Out Port
  - 2 x USB 2.0 Ports
  - 1 x eSATA Connector
  - 2 x USB 3.1 Gen1 Ports (AMD A88X (Bolton-D4))
  - 2 x USB 3.1 Gen1 Ports (ASMedia ASM1042)
  - 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED)
  - HD Audio Jacks: Rear Speaker / Central / Bass / Line in / Front Speaker / Microphone
• Unique Feature
  - ASRock A-Tuning
  - ASRock APP Shop
  - ASRock Instant Boot
  - ASRock Instant Flash
  - ASRock APP Charger
  - ASRock XFast USB
  - ASRock XFast RAM
  - ASRock Crashless BIOS
  - ASRock OMG (Online Management Guard)
  - ASRock Internet Flash
  - ASRock UEFI System Browser
  - ASRock UEFI Tech Service
  - ASRock Dehumidifier Function
  - ASRock Easy RAID Installer
  - ASRock Easy Driver Installer
  - ASRock Interactive UEFI
  - ASRock Fast Boot
  - ASRock X-Boost
  - ASRock Restart to UEFI
  - ASRock USB Key
  - ASRock FAN-Tastic Tuning
  - Hybrid Booster:
  - ASRock U-COP
• Support CD
  - Drivers, Utilities, AntiVirus Software (Trial Version), CyberLink MediaEspresso 6.5 Trial, Google Chrome Browser and Toolbar, Start8 (30 days trial)
• Accessories
  - Quick Installation Guide, Support CD, I/O Shield
  - 4 x SATA Data Cables
• Hardware Monitor
  - CPU temperature sensing
  - Chassis temperature sensing
  - CPU Fan Tachometer
  - Chassis Fan Tachometer
  - CPU, Chassis Quiet Fan
  - CPU, Chassis Fan multi-speed control
  - CASE OPEN detection
  - Voltage monitoring: +12V, +5V, +3.3V, Vcore
• Form Factor
  - ATX Form Factor
  - Premium Gold Capacitor design (100% Japan made high quality conductive polymer capacitors)
• OS
  - Microsoft Windows^® 10 64-bit / 8.1 32-bit / 8.1 64-bit / 8 32-bit / 8 64-bit / 7 32-bit / 7 64-bit



  *Carrizo FM2r2 processor supports Windows^® 10 64-bit / 8.1 64-bit / 7 32-bit / 7 64-bit only.
• Certifications
  - FCC, CE
  - ErP/EuP ready (ErP/EuP ready power supply is required)
