• CPU
  - Support for Socket FM1 100W processors
  - Supports AMD's Cool 'n' Quiet Technology
  - UMI-Link GEN2
• Chipset
  - AMD A75 FCH (Hudson-D3)
• Memory
  - Dual Channel DDR3 memory technology
  - 2 x DDR3 DIMM slots
  - Supports DDR3 2400+(OC)/1866/1600/1333/1066/800 non-ECC, un-buffered memory
  - Max. capacity of system memory: 16GB*



  *Due to the operating system limitation, the actual memory size may be less than 4GB for the reservation for system usage under Windows^® 32-bit OS. For Windows^® 64-bit OS with 64-bit CPU, there is no such limitation.
• BIOS
  - 32Mb AMI UEFI Legal BIOS with GUI support
  - Supports "Plug and Play"
  - ACPI 1.1 Compliance Wake Up Events
  - Supports jumperfree
  - SMBIOS 2.3.1 Support
  - DRAM, VDDP, SB Voltage Multi-adjustment
• Graphics
  - Integrated AMD Radeon HD 65XX/64XX graphics in Llano APU
  - DirectX 11, Pixel Shader 5.0
  - Max. shared memory 512MB
  - Two graphics output options: Support HDMI and D-Sub ports by independent display controllers
  - Supports HDMI Technology with max. resolution up to 1920x1200 @ 60Hz
  - Supports D-Sub with max. resolution up to 1920x1600 @ 60Hz
  - Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and HBR (High Bit Rate Audio) with HDMI (Compliant HDMI monitor is required)
  - Supports Blu-ray Stereoscopic 3D with HDMI
  - Supports AMD Steady Video™: New video post processing capability for automatic jitter reduction on home/online video
  - Supports HDCP function with HDMI port
  - Supports Full HD 1080p Blu-ray (BD) / HD-DVD playback with HDMI port



  *Some of AMD FM1 CPU (i.e AMD Athlon/Sempron family FM1 CPU) does not have integrated graphics processor. When this kind of CPU is installed, a discrete VGA card is required.
• Audio
  - 5.1 CH HD Audio (VIA^® VT1705 Audio Codec)
• LAN
  - PCIE x1 Gigabit LAN 10/100/1000 Mb/s
  - Realtek RTL8111E
  - Supports Wake-On-LAN
  - Supports LAN Cable Detection
  - Supports Energy Efficient Ethernet 802.3az
  - Supports PXE
• Slots
  - 1 x PCI Express 2.0 x16 slot
  - 1 x PCI Express 2.0 x1 slot
  - 1 x PCI slot
  - Supports AMD Dual Graphics
• Connector
  - 6 x SATA3 6.0 Gb/s connectors, support RAID (RAID 0, RAID 1 and RAID 10), NCQ, AHCI and Hot Plug functions
  - 1 x IR header
  - 1 x CIR header
  - 1 x Print port header
  - 1 x COM port header
  - CPU/Chassis/Power FAN connector
  - 24 pin ATX power connector
  - 8 pin 12V power connector
  - Front panel audio connector
  - 3 x USB 2.0 headers (support 6 USB 2.0 ports)
• Rear Panel I/O
  I/O Panel
  - 1 x PS/2 Mouse Port
  - 1 x PS/2 Keyboard Port
  - 1 x D-Sub Port
  - 1 x HDMI Port
  - 2 x USB 2.0 Ports
  - 4 x USB 3.1 Gen1 Ports
  - 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED)
  - HD Audio Jack: Line in / Front Speaker / Microphone
• Unique Feature
  - ASRock Extreme Tuning Utility (AXTU)
  - ASRock Instant Boot
  - ASRock Instant Flash
  - ASRock APP Charger
  - ASRock XFast USB
  - ASRock XFast RAM
  - Hybrid Booster:
  - ASRock U-COP
• Support CD
  - Drivers, Utilities, AntiVirus Software (Trial Version), CyberLink MediaEspresso 6.5 Trial
• Accessories
  - Quick Installation Guide, Support CD, I/O Shield
  - 2 x SATA Data Cables (optional)
• Hardware Monitor
  - CPU Temperature Sensing
  - Chassis Temperature Sensing
  - CPU, Chassis, Power Fan Tachometer
  - CPU, Chassis Quiet Fan
  - CPU, Chassis Fan multi-speed control
  - Voltage Monitoring: +12V, +5V, +3.3V, Vcore
• Form Factor
  - Micro ATX Form Factor: 8.9-in x 8.5-in, 22.6 cm x 21.6 cm
  - Solid Capacitor for CPU Power
• OS
  - Microsoft Windows^® 8 / 8 64-bit / 7 / 7 64-bit / Vista™ / Vista™ 64-bit / XP / XP 64-bit compliant
• Certifications
  - FCC, CE
  - ErP/EuP Ready (ErP/EuP ready power supply is required)
