| Form Factor | |
| Dimensions | - Mini-ITX (6.7-in x 6.7-in) |
| Processor System | |
| CPU | - Intel® Dual-Core Atom™ PineView Processor N445/D425/D525 - Supports Hyper-Threading Technology |
| Core Number | - D525 : 2 ; D425/N455 : 1 |
| Max Speed | - D525/D425: 1.8 GHz, N455: 1.66 GHz |
| L3 Cache | - N/A |
| Chipset | - NM10 |
| BIOS | - UEFI |
| Expansion Slot | |
| PCI | - 1 |
| Mini-PCIe | - 1 (Full Size) |
| mSATA | - 0 |
| PCIe | - 0 |
| CFast Card Socket | - 0 |
| Memory | |
| Technology | - D525/D425: Single Channel DDR3 800 MHz SDRAM - N455: Single Channel DDR3 667 MHz SDRAM |
| Max. | - D525/D425: 4GB - N455: 2GB |
| Socket | - 2 x SO-DIMM |
| Graphics | |
| Controller | - Intel® Graphics Media Accelerator 3150 - Pixel Shader 2.0, DirectX 9.0 |
| VRAM | - Shared Memory |
| VGA | - D525/D425: supports max. resolution 2048x1536 @ 60Hz - N455: supports max. resolution 1400x1050 @ 60Hz |
| LVDS | - Single Channel 18bits, max resolution 1366x768 |
| HDMI | - No |
| DVI | - No |
| DisplayPort | - No |
| MultiDisplay | - Yes |
| Ethernet | |
| Ethernet | - 10/100/1000 Mbps |
| Controller | - GbE LAN: 2 x Realtek RTL8111E-VL |
| Connector | - 2 x RJ-45 |
| SATA | |
| Max Data Transfer Rate | - SATA2 (3.0Gb/s), SATA3 (6.0Gb/s), Supports RAID 0/1 |
| Rear I/O | |
| VGA | - 1 x D-Sub |
| DVI | - 0 |
| HDMI | - 0 |
| DisplayPort | - 0 |
| Ethernet | - 2 |
| USB | - 4 (USB 2.0 compliant) |
| Audio | - 2 (Mic-in, Line-out) |
| Serial | - 3 (RS-232/422/485) |
| PS2 | - 2 (1 x keyboard and 1 x mouse) |
| Internal Connector | |
| USB | - 4 (USB 2.0 compliant) |
| LVDS / inverter | - 1/1 |
| VGA | - 0 |
| Serial | - 3 (RS-232) |
| SATA | - 2 x SATA2 (3.0Gb/s), 2 x SATA3 (6.0Gb/s), Support RAID 0/1 |
| mPCIe | - 1 |
| Parallel | - 1 |
| mSATA | - 0 |
| IrDA | - 0 |
| GPIO 8-bit | - 4 x GPI + 4 x GPO |
| SATA PWR Output Con | - 2 |
| Speaker Header | - 1 |
| Watchdog Timer | |
| Output | - From Super I/O to drag RESETCON# |
| Interval | - 256 segments, 0,1,2…255sec/min |
| Power Requirements | |
| Input PWR | - 12V DC-In (4-pin ATX PWR Con) |
| Power On | AT/ATX Supported - AT : Directly PWR on as Power input ready - ATX : Press Button to PWR on after Power input ready |
| Environment | |
| Temperature | - 0ºC – 60ºC |
The specification is subject to change without notice in advance. The brand and product names are trademarks of their respective companies. Any configuration other than original product specification is not guaranteed.
