• A-Style
  - ASRock Cloud
• CPU
  - Supports Socket FM2+ 95W / FM2 100W processors
  - 4 + 2 Power Phase design
• Chipset
  - AMD A88X (Bolton-D4)
• Memory
  - Dual Channel DDR3 Memory Technology
  - 4 x DDR3 DIMM Slots
  - Supports DDR3 2600+(OC)/2400(OC)/2133/1866/1600/1333/1066 non-ECC, un-buffered memory
  - Max. capacity of system memory: 64GB**
  - Supports Intel^® Extreme Memory Profile (XMP) 1.3 / 1.2
  - Supports AMD Memory Profile Technology (AMP) up to AMP 2400



  *DDR3 2600+ is only supported with two DIMMs.

  **Due to the operating system limitation, the actual memory size may be less than 4GB for the reservation for system usage under Windows^® 32-bit OS. For Windows^® 64-bit OS with 64-bit CPU, there is no such limitation.
• BIOS
  - 64Mb AMI UEFI Legal BIOS with GUI support
  - Supports "Plug and Play"
  - ACPI 1.1 Compliant wake up events
  - Supports jumperfree
  - SMBIOS 2.3.1 support
  - DRAM, VDDP, VDDR Voltage multi-adjustment
• Graphics
  - Integrated AMD Radeon™ R7/R5 Series Graphics in A-series APU
  - DirectX 11.1, Pixel Shader 5.0 with FM2+ CPU. DirectX 11, Pixel Shader 5.0 with FM2 CPU.
  - Max. shared memory 2GB
  - Three graphics output options: D-Sub, DVI-D and HDMI
  - Supports Triple Monitor
  - Supports HDMI with max. resolution up to 4K x 2K (4096x2160) @ 24Hz
  - Supports Dual-link DVI-D with max. resolution up to 2560x1600 @ 60Hz
  - Supports D-Sub with max. resolution up to 1920x1200 @ 60Hz
  - Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and HBR (High Bit Rate Audio) with HDMI Port (Compliant HDMI monitor is required)
  - Supports Blu-ray Stereoscopic 3D with HDMI Port
  - Supports AMD Steady Video™ 2.0: New video post processing capability for automatic jitter reduction on home/online video
  - Supports HDCP with DVI-D and HDMI Ports
  - Supports Full HD 1080p Blu-ray (BD) playback with DVI-D and HDMI Ports



  *Only FM2+ APU can support up to 4096x2160 resolution display VIA^® HDMI port.
• Audio
  - 7.1 CH HD Audio with Content Protection (Realtek ALC892 Audio Codec)
  - Premium Blu-ray Audio support
  - TI^® NE5532 Premium Headset Amplifier (Supports up to 600 ohm headsets)
• LAN
  - PCIE x1 Gigabit LAN 10/100/1000 Mb/s
  - Qualcomm^® Atheros^® AR8171
  - Supports Qualcomm^® Atheros^® Security Wake On Internet Technology
  - Supports Wake-On-LAN
  - Supports Energy Efficient Ethernet 802.3az
  - Supports PXE
• Slots
  - 1 x PCI Express 3.0 x16 Slot (PCIE2 @ x16 mode)
  - 1 x PCI Express 2.0 x16 Slot (PCIE4 @ x4 mode)
  - 2 x PCI Express 2.0 x1 Slots
  - 3 x PCI Slots
  - Supports AMD Quad CrossFireX™, CrossFireX™ and Dual Graphics



  *PCIE 3.0 is only supported with FM2+ CPU. With FM2 CPU, it only supports PCIE 2.0.
• Storage
  - 7 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0, RAID 1, RAID 5 and RAID 10), NCQ, AHCI and Hot Plug
• Connector
  - 1 x IR Header
  - 1 x COM Port Header
  - 1 x Chassis Intrusion Header
  - 1 x TPM Header
  - 1 x Power LED Header
  - 2 x CPU Fan Connectors (1 x 4-pin, 1 x 3-pin)
  - 3 x Chassis Fan Connectors (1 x 4-pin, 2 x 3-pin)
  - 1 x Power Fan Connector (3-pin)
  - 1 x 24 pin ATX Power Connector
  - 1 x 8 pin 12V Power Connector
  - 1 x Front Panel Audio Connector
  - 3 x USB 2.0 Headers (Support 6 USB 2.0 ports)
  - 1 x USB 3.1 Gen1 Header by AMD A88X (Bolton-D4) (Supports 2 USB 3.1 Gen1 ports)
• Rear Panel I/O
  - 1 x PS/2 Mouse/Keyboard Port
  - 1 x D-Sub Port
  - 1 x DVI-D Port
  - 1 x HDMI Port
  - 1 x Optical SPDIF Out Port
  - 2 x USB 2.0 Ports
  - 1 x eSATA Connector
  - 2 x USB 3.1 Gen1 Ports (AMD A88X (Bolton-D4))
  - 4 x USB 3.1 Gen1 Ports (Etron EJ188)
  - 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED)
  - 1 x Clear CMOS Switch with LED
  - HD Audio Jacks: Rear Speaker / Central / Bass / Line in / Front Speaker / Microphone
• Unique Feature
  - ASRock A-Tuning
  - ASRock APP Shop
  - ASRock Instant Boot
  - ASRock Instant Flash
  - ASRock APP Charger
  - ASRock XFast USB
  - ASRock XFast RAM
  - ASRock Crashless BIOS
  - ASRock OMG (Online Management Guard)
  - ASRock Internet Flash
  - ASRock UEFI System Browser
  - ASRock UEFI Tech Service
  - ASRock On/Off Play Technology
  - ASRock Dehumidifier Function
  - ASRock Easy RAID Installer
  - ASRock Easy Driver Installer
  - ASRock Interactive UEFI
  - ASRock Fast Boot
  - ASRock X-Boost
  - ASRock Restart to UEFI
  - ASRock USB Key
  - ASRock FAN-Tastic Tuning
  - Hybrid Booster:
  - ASRock U-COP
• Support CD
  - Drivers, Utilities, AntiVirus Software (Trial Version), CyberLink MediaEspresso 6.5 Trial, Google Chrome Browser and Toolbar, Start8 (30 days trial)
• Accessories
  - Quick Installation Guide, Support CD, I/O Shield
  - 4 x SATA Data Cables
• Hardware Monitor
  - CPU temperature sensing
  - Chassis temperature sensing
  - CPU Fan Tachometer
  - Chassis Fan Tachometer
  - CPU, Chassis Quiet Fan
  - CPU, Chassis Fan multi-speed control
  - CASE OPEN detection
  - Voltage monitoring: +12V, +5V, +3.3V, Vcore
• Form Factor
  - ATX Form Factor
  - ASRock DuraCap (2.5 x longer life time) (100% Japan made high quality conductive polymer capacitors)
• OS
  - Microsoft Windows^® 10 64-bit / 8.1 32-bit / 8.1 64-bit / 8 32-bit / 8 64-bit / 7 32-bit / 7 64-bit



  *Carrizo FM2r2 processor supports Windows^® 10 64-bit / 8.1 64-bit / 7 32-bit / 7 64-bit only.
• Certifications
  - FCC, CE
  - ErP/EuP ready (ErP/EuP ready power supply is required)

The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing Administrator, Inc. in the United States and other countries.

The specification is subject to change without notice in advance. The brand and product names are trademarks of their respective companies. Any configuration other than original product specification is not guaranteed.

The above user interface picture is a sample for reference. The actual user interface may vary with the updated software version.
